Loxxer LOXK2000VDMA-AEROSOL-KIT

LOXK2000 aerosol fire suppression system

The AFX 150 is an electrically activated aerosol extinguishing module (6-36 V DC, 1 A for 1-2 seconds) with a net weight of 150 g of extinguishing agent. It weighs a total of 2.5 kg and discharges the aerosol via a standard outlet opening with a range of 1.5 m in less than 30 seconds. The dimensions are 310 mm in length and 94 mm in diameter.

It is a reliable aerosol fire extinguishing system specifically designed for use in enclosed environments such as battery cabins. When smoke is detected, the system is automatically activated and releases a fine aerosol that is quickly dispersed throughout the cabin interior.

This advanced aerosol interrupts the chemical chain reaction of a fire and simultaneously reduces the temperature in the affected area to effectively prevent the spread and thermal runaway of battery cells. The system enables fast and effective firefighting - without the need for pipes or pressurized containers - and is ideal for compact, safety-critical applications.

The aerosol can only be ordered in conjunction with the cabinet!

Key features:

• Immediate activation upon smoke detection

• Rapid and complete distribution of the aerosol in the enclosure

• Combined effect: fire suppression and cooling

• Maintenance-free system with long service life

• Residue-free, environmentally friendly operation
